Plastic Surface Cleaner

Plastic Surface Cleaner

The Plastic Surface Cleaner features a dual-nozzle rotating spray bar that continuously sprays high-pressure water onto the surface, reducing the need for point-by-point cleaning with a handheld spray gun. It is suitable for hard surfaces such as concrete, brick, tile, driveways, patios, and parking lots.

Description

The Plastic Surface Cleaner features a dual-nozzle rotating spray bar that continuously sprays high-pressure water onto the surface, reducing the need for point-by-point cleaning with a handheld spray gun. It is suitable for hard surfaces such as concrete, brick, tile, driveways, patios, and parking lots.



Core Advantages



Dual-Nozzle Rotation: Two high-pressure nozzles drive the spray bar to rotate via the reaction force of the water flow, creating a continuous water spray that reduces repetitive movement during large-area cleaning.



Rotating Spray Bar: The continuous rotation of the spray bar allows the high-pressure water streams to overlap and cover the cleaning area, helping to reduce cleaning streaks caused by the movement of a stationary spray gun.



Sealed Rotating Structure: The rotating assembly uses stainless steel, brass, and a sealed structure to reduce the ingress of water and impurities into the rotating mechanism, maintaining stable operation.



K/D Handle: The handle is detachable for easy packaging, storage, and transportation.



Technical Specifications



Parameter

Specification

Product Name

Plastic Surface Cleaner

Model

SC-P15 / SC-P20

Cleaning Width

380 mm / 500 mm

Housing Material

UV-Resistant Heavy-Duty PP

Max. Pressure

4,000 PSI / 275 Bar

Recommended Pressure

2,500–3,200 PSI / 170–220 Bar

Max. Flow Rate

4.0 GPM / 15.0 LPM

Recommended Flow Rate

2.5–3.5 GPM / 9.5–13.2 LPM

Max. Temperature

60°C / 140°F

Inlet Connection

1/4" Quick-Connect

Swivel Assembly

Stainless Steel & Brass

Nozzle

2 × Stainless Steel, 1/4" Thread

Spray Angle

25°

Caster Wheels

4 × 360° Non-Marking Casters

Skirt

Nylon Splash-Reducing Bristles

Handle

Detachable K/D Steel Handle

Net Weight

3.2 kg / 4.5 kg

Compatible Equipment

Electric & Gas Pressure Washers

OEM/ODM

Logo, Color, Packaging & Adapter



Compatibility



Pressure and Flow Matching: Select the appropriate nozzle size based on the PSI and GPM of the high-pressure washer to maintain suitable rotation speed and cleaning effect.



Interface Compatibility: Standard 1/4" Quick-Connect, with various adapter options available depending on the host model.



Power Compatibility: Suitable for electric and gasoline-powered high-pressure washers.



Product Details



PP Cleaning Tray: Made of impact-resistant PP material, balancing structural strength and product weight; custom colors available upon order.



Stainless Steel Nozzle: Removable design for easy cleaning, replacement, and maintenance.



Nylon Splash Skirt: Reduces high-pressure water flow and wastewater splashing, keeping the cleaning area clean.



Inlet Filter: Blocks impurities in the water path, reducing the risk of nozzle clogging.



Quality Control



Incoming Material Inspection: Inspects key components such as PP material, metal parts, nozzles, and seals.



Assembly Inspection: Inspects interfaces, rotating components, casters, and product appearance.



Pressure and Leakage Testing: Checks the sealing performance of the water path and rotating components according to internal quality standards.



Outgoing Inspection: Performs random or full inspection of finished products according to order requirements; QC records are available.



OEM / ODM Customization



Product Customization: Supports customization of logo, color, nameplate, interface, and nozzle specifications.



Packaging Customization: Supports color boxes, outer cartons, barcodes, brand labels, and multilingual instruction manuals.



Sample Development: Product adjustments can be made based on drawings, samples, or specifications; lead time depends on the customization details.



Packaging & Supply



Export Packaging: Handles and discs can be packaged separately, suitable for sea freight, wholesale, and e-commerce channels.



Bulk Supply: Supports standard products, small-batch purchases, and OEM orders; MOQ and lead time are confirmed according to the order.



Spare Parts Supply: Common spare parts such as nozzles, O-rings, filters, and casters are available.



Purchasing Information



MOQ & Sample: Supports sample testing and bulk purchases; OEM MOQ is confirmed based on model and customization details.



Lead Time: Standard products and customized orders are produced separately; specific lead time is confirmed based on quantity and customization requirements.



Warranty & After-Sales: Warranty, spare parts, and after-sales technical support are available; specific terms are confirmed according to the order.



Export Data: Carton data is available. Size, Qty/Carton, Gross Weight, CBM and Container Loading Quantity.



FAQ



Q: What pressure washer specifications are required?

A: Recommended pressure is 2,500–3,200 PSI with 2.5–3.5 GPM flow.

Q: Can you provide different adapters?

A: Yes. 1/4" Quick-Connect is standard. Other adapters are available according to the machine model.

Q: Can the nozzle size be customized?

A: Yes. Nozzle orifice can be selected according to pressure and flow requirements.

Q: What is the OEM MOQ?

A: MOQ depends on model, quantity and customization requirements.

Q: Are samples available?

A: Yes. Samples are available for product evaluation before bulk orders.

Q: Do you supply spare parts?

A: Yes. Nozzles, O-rings, filters and casters are available.

Q: What information is needed for a quotation?

A: Model, quantity, target market, connection, packaging and OEM requirements.
